8 wall hanging type digital display temperature transmitter
Product description:
8 wall hanging type digital display temperature transmitter
8 wall hanging digital display temperature transmitter adopts imported original components, stable and reliable performance, small size, easy installation.
The bridge circuit measurement technology unique to our company in the design, with no temperature drift, no lead resistance, strong anti-interference ability, the advantages of bridge circuit and measurement circuit complete isolation etc..
Main technical parameters of 8 wall hanging digital display temperature transmitter:
RTD signal input
8 way RTD signal isolation input, three line connection method;
1 way isolated RS485 communication interface, communication baud rate 9600 ;
Operating voltage: 24VDC
Operating temperature (range): 0~100 DEG C (adjustable)
Sperm degree: 0.2%
Working environment: -40 ~ +80 DEG C
Support MODBUSRTU specification
The measuring range is C50 DEG C, ~300 DEG C
The measuring resolution is 0.1 degrees centigrade
The conversion accuracy is + 0.1 centigrade
Temperature measuring accuracy: + 0.2
The temperature stability is better than that of 100PPMM
Isolation voltage is less than 1500V
Temperature stability characteristic better than 100PPMM
Serial parameters: 9600, N, 8,1
